The ABR-460.4 is a high-power Class AB 4-channel amplifier delivering up to 230W RMS per channel at 2 ohms. Designed for clean, detailed sound, it features a wide 10Hz–20kHz frequency response, built-in high/low-pass filters, and a 12 dB/oct crossover. Perfect for serious car audio upgrades.

Specifications:

• Model: ABR-460.4

• Amplifier Class: AB

• Number of Channels: 4

• Frequency Response: 10 – 20,000 Hz

• RMS Power @ 2 Ohms (14.4V): 230 W × 4

• RMS Power @ 4 Ohms (14.4V): 115 W × 4

• RMS Power @ 4 Ohms (Bridged): 460 W × 2

• Minimum Permissible Load per Channel: 2 Ohms

• Minimum Permissible Load (Bridged): 4 Ohms

• Input Sensitivity (SPL): 0.2 – 6 V

• Low Pass Filter Range: 50 – 250 Hz

• High Pass Filter Range: 120 – 3000 Hz

• Crossover Slope: 12 dB/Oct

• Damping Factor: ≥ 100

• Signal-to-Noise Ratio: ≥ 92 dB

• Operating Voltage: 9 – 15 V

• Dimensions (W × L × H): 14.96 × 8.66 × 1.93 inches

• Gross Weight: 7.36 lb (3.34 kg)

• UPC: 4650185705762
