Pride M6.12S04 Subwoofer Pride M6.12 RMS 600W Size 12" S0.4
Subwoofer Pride M6.12
Turn up the volume and get ready for an amazing audio experience in your car with the Pride M6.12 subwoofer speaker. Specially designed to achieve powerful sound, this car subwoofer is sure to make your trip more memorable.
With a power rating (RMS) of 600W, the Pride M6.12 is ready to produce booming bass that will pierce your body and enhance your favorite music. The 2″ round copper voice coil ensures reliability and durability, while the polyimide voice coil insulation material ensures bass purity and clarity.
This subwoofer speaker features a steel base frame for strength and stability, and has an impedance of 2+2 ohms. Simple installation and easy operation ensure that you will enjoy this subwoofer in your car.
For lovers of powerful sound and style, the Pride M6 12 is the perfect choice. It will give you an enjoyable sound experience and a stylish appearance that will add a personal touch to your car. Don’t wait any longer, place your order for Pride M6 12 and enjoy loud bass in your car.
Subwoofers manufactured by the leading company Pride stand out among their analogues with the following advantages:
Hot pressing of the washers and the use of woven material for the centering washers allows you to realize the full potential of the speaker under various operating conditions.
Automated gluing of magnetic systems to test the magnetic system according to all characteristics.
Special glue for each unit of the Pride acoustics allows for maximum strength and elasticity of the moving units.
Acoustic meshes are designed individually for the entire model range, therefore they effectively protect diffusers from mechanical damage
Please yourself with powerful bass, clear sound and reliable equipment with Pride Car Audio!
Subwoofer available in the USA! General feature
Power Handling (RMS) 600 W
VC diameter / material 2" round copper
VC wire insulation Polyimide
Frame material Steel
Magnet size and q-ty 140*20 mm x 2 pcs / 5,51*0,79" x 2 pcs
Spider diameter and q-ty 160 mm x 2 pcs / 6,3" x 2 pcs
Cone material Paper with glass fiber
Dust cap material Hi-temp ABS
Parameters
DC Resistance (Re) 1,7+1,7 Ω
Free Air Resonance (Fs) Hz 34,1
Moving Mass (Mms) g 205
BL Tm 13,9
Total Speaker “Q” (Qts) 0,56
Electrical Q (Qes) 0,63
Mechanical Q (Qms) 5,32
Equivalent Compliance (Vas) L 38,2
One-Way Linear Excursion (Xmax) (BL 50%) mm 15
Sensitivity (1 W / 1 m) dB 86,8
Effective Piston Area (Sd) cm² 507
Physical Specifications
Overall Diameter 316 mm / 12,44 inch
Mounting Hole Diameter 279 mm / 10,99 inch
Mounting Depth 142,5 mm / 5,61 inch
Driver Displacement 2 l / 0,53 Gal
Net Weight 5,6 kg / 11,02 lbs
