DS18 DDX10.5ML 10.5" Floating Adjustable Modular Touchscreen Mechless Single-DIN Head Unit with Bluetooth, Mirror Link and USB
DS18 DDX10.5ML
10.5” Mechless Single-Din Floating Display Digital Media Receiver With Mirror Link For iOS & Android / BT / AUX / USB / SD / AM / FM
The Flawless Touch Screen Control supported by all DS18’s Receivers returns for seamless maneuvering through the numerous features available in this upgraded model.
This receiver will include everything you need to bring your multimedia dreams to life, including Wi-Fi, Bluetooth, AUX, USB, SD, phone controls, and all your AM / FM stations.
Connecting your head unit to your mobile hotspot makes accessing the available options to this receiver much easier.
These receivers are mech-less; this means that they don’t support the play of compact discs and only play music back from digital media players. That’s why we’ve included so many options for playing music back from your digital devices.
Set up Mirror link to display all media from your phone on the device. You can also connect to this device using Bluetooth v5.0, USB, an SD Card, or an AUX cable for direct access to any device. Your new DDX10.5ML also comes with AM/FM stations for when you don’t want to choose between your many audio sources.
This receiver does it all and has the power to support it: with 4CH x 15W RMS and, 4CH x 40W MAX at 4 ohms this receiver has just enough power to charge most entry level speakers.
Features:
- 10.5" Single Din Digital Media Receiver
- Floating Display ~ Mech-Less
- BT ~ USB ~ SD ~ AUX ~ AM/FM ~ SWC
- Mirror Link IOS and Android
- Touchscreen
- Screen with adjustable angle
Specs:
SKU: DDX10.5ML
Rated power source: 14.4V DC (10.8V to 15V operation)
Maximum Current Consumption: 10 Amp
Dimensions (W x H x D): Chassis: 178mm x 50mm x 115mm Bezel frame: 170mm x 46mm x 5mm Screen Frame: 266mm x 180mm
Weight: 4.5Lb
Display:
Screen Size / Aspect Ratio: 10.5 inch / Wide 16:9
Pixels: 1280 x 720
Display Type: IPS / Full HD / Capacitive Touch Screen
Temperature Operation: -20C to +60C (14F to 140F)
Audio:
Maximum Power Output: 45W X 4 Ch / 4 ohm
Continuous Power Output: 15W x 4 Ch / 4 ohm
Pre-output Level: 4.5 Volts (Front, Rear) 7 Volts (Subwoofer)
Equalizer: 16 bands (35Hz, 60Hz, 80Hz, 120Hz, 160Hz, 250Hz, 320Hz, 400Hz, 600Hz, 800Hz, 1KHz, 3KHz, 5KHz, 8KHz, 12.5Khz, 16Khz)
Gain: +/- 12dB
Audio Control: Volume / Balance / Fader /Loudness
Tuner:
Frequency Range: FM: 87.5 ~ 107.9 KHz AM: 530 ~ 1710 KHz
Presets Memory: 30 Stations (18 FM/12 AM)
Region: Selectable (USA, Latin, Japan, Asia, Europe, OIRT, Australia, Mid-East)
Sensitivity Adjustment: LOC (On/Off) / ST (On/Off)
USB / SD Player / Connectivity:
Type / Class: V1.1 / V2.0 / MSC / MTP / FAT16 / FAT32 / NTFS
Format Files Supported: RMVB, MPG4, AVI, MP3, WMA, JPEG, DivX
Resolution Supported: 1080P Video
Memory Size Reader: up to 64 Gb
Max Current Supply: 1.5 Amp (USB)
Number of USB Ports: 2 (1 x Front, 1 x Rear)
Bluetooth Version / Services: V5.0 / Audio Streaming / Hands Free calls
Camera Input: RCA Analog Video up to HD 720p (Front/Rear)
Video Output: Dual RCA (1 Volt/75 ohm)
A/V Aux Input: Rear RCA Audio and Video / Front 3.5mm Jack Stereo Audio
Microphone: 3.5mm Jack external MIC Input
Remote Control: Frontal IR Receptor / Wired (3.5mm jack) Input
