Audio Control LC-1.1500 LC Series High-Power Monoblock Amplifier with AccuBASS

The AudioControl LC-1.1500 high-power monoblock amplifier delivers 1500W at 2 Ohm for clean, powerful bass in any car audio setup. Featuring AccuBASS® technology, it overcomes factory bass roll-off and heavily equalized systems, ensuring loud, articulate bass. With wide voltage inputs, versatile connections, and superior reliability, the LC-1.1500 is perfect for serious car audio upgrades.

Features:

• Subwoofer amplifier with patented AccuBASS®
• 1500 watts @ 2 ohms
• 850 watts @ 4 ohms
• AccuBASS® Processing
• MILC™ Maximum Input Level Control (Patent Pending)
• GTO™ Signal Sense
• 24 dB/octave Linkwitz-Riley Alignment crossover
• Speaker level and preamp inputs
• Optional ACR-1 assignable remote control
• Solid One-Piece Aluminum Chassis


Specifications:

Inputs

Preamp Inputs: 2 balanced

Input Voltage Range: 500 mV – 6 Vrms

Speaker Level Inputs: 2

Speaker Level Input Voltage Range: 3 V – 40 Vrms

Outputs

Rated Continuous (RMS) Power at 14.4V:

4 Ω – 850 W RMS

2 Ω – 1500 W RMS

Performance

Frequency Response: 10 Hz – 30 kHz

Signal to Noise: 102 dBa, Ref 850 W @ 4 Ohm

Damping Factor: 670 at 10 V, 4 Ohm Output, 100 Hz

THD+N: < 0.01%

Minimum Power / Ground Wire Gauge: 0 AWG wire

Fuse Rating: 4 x 40 A

Crossover: 24 dB/octave Linkwitz-Riley, Adjustable From 30 Hz – 230 Hz

PFM Subsonic Filter: 24 Hz

Weight & Dimensions

Dimensions: 12″W x 7.95″D x 2.1″H

Weight: 7.2 lbs (3.3 kg)

Fuse Rating: 4 x 40 A

What's in the Box: LC-1.1500, Speaker connectors, Fuses, Manual

UPC: 851523007454
