Sundown Audio HZ-900.5 Horizon Series 5-Channel Amplifier — 100 Watts RMS x 4 at 4 Ohms + 500 Watts RMS x 1 at 1 Ohm
The Sundown Audio HZ-900.5 is a compact 5-channel Class D amplifier from the Horizon Series, engineered for clean, controlled power in tight spaces. Its heavy-duty aluminum heat sink ensures stable performance and efficient cooling during high-output use. Perfect for car audio enthusiasts seeking premium sound and space-saving design.
Features:
- 5-channel car amplifier
- 100W RMS x 4 + 200W RMS x 1 @ 4Ω
- 150W RMS x 4 + 250W RMS x 1 @ 2Ω
- 300W RMS x 2 @ 4Ω (bridged, channels 1–4)
- 500W RMS x 1 @ 1Ω (channel 5)
- Variable high-pass filters (channels 1–4)
- Variable low-pass filter (channel 5)
- Subsonic filter on channel 5: 10–50 Hz (12 dB/oct)
- Wired 16' remote level control for channel 5
- Class D amp technology
- Aluminum heat sink
- Preamp & speaker-level inputs (converter required for speaker-level)
- Wiring & hardware not included
- Requires 4-gauge power/ground leads & 100A fuse
- Set-screw speaker terminals accept up to 10-gauge wire
Specifications:
RMS Power Output: 100 W x 4 channels + 500 W x 1 channel
Power at 2 Ohms: 150 W x 4 channels
Power at 1 Ohm: 500 W x 1 channel
Bridged Power: 300 W x 2 channels
Minimum Impedance (Bridged): 4 Ω
Minimum Impedance (Unbridged): 2 Ω
Signal-to-Noise Ratio: 95 dB
Input Voltage: 14.4 V
Amplifier Class: D
Built-in DSP: No
Remote Control: Yes
Low-Pass Crossover Frequency: 50–250 Hz
Low-Pass Slope: 12 dB/oct
High-Pass Crossover Frequency: 27–250 Hz
High-Pass Slope: 12 dB/oct
Bass Boost: No
Fan Cooled: No
Fuse Rating: 100 A
Speaker Level Inputs: No
Preamp Outputs: No
Width: 11-3/8 in
Height: 2-1/4 in
Depth: 4-5/8 in
UPC: 810111135634
