Stetsom STE-BRAVOFULL5K1 BRAVO FULL 5K Digital Full-Range Amplifier Mono 1 Channel Class D 5000 Watts RMS
High power amplification with Stetsom BRAVO FULL 5K Digital Full-Range Mono 1-Channel Class D Amplifier, delivering up to 5000 Watts RMS of power. Delivers dynamic sound with superior control and accuracy. Perfect for professional audio applications.
TECHNICAL SPECIFICATIONS:
| Outpout Impedance | 1 Ohm | 2 Ohms |
| Number of Channels | 1 | 1 |
| RMS Power at 1 Ohm @ 14.4V | 5300W | 5300W |
| RMS Power at 2 Ohms @ 14.4V | 3300W | 3000W |
| RMS Power at 1 Ohm @ 12.6V | 5000W | 5000W |
| RMS Power at 2 Ohms @ 12.6V | 2800W | 2600W |
| Minimum input sensitivity | 200mV | 200mV |
| Signal to noise ratio | >90dB | >90dB |
| Frequency response (-3dB) | 10Hz ~ 12KHz | 10Hz ~ 12KHz |
| Crossover low pass | 90Hz ~ 12KHz | 90Hz ~ 12KHz |
| Crossover high pass | 10Hz ~ 90Hz | 10Hz ~ 90Hz |
| Bass boost | Freq: 30Hz ~ 70Hz / Boost: 0dB ~ +10dB | Freq: 30Hz ~ 70Hz / Boost: 0dB ~ +10dB |
| Input impedance | 12K Ohms | 12K Ohms |
| Supply voltage | 9V ~ 16V DC | 9V ~ 16V DC |
| Musical/Bass consumption | 242A/485A | 227A/445A |
| Dimensions (H x W x L) | 3.14" x 9.11" x 13.11" | 3.14" x 9.11" x 13.11" |
| Weight | 9.36 lb | 9.36 lb |
Free shipping is available within the 48 U.S. states. Orders placed before 11 PM ET are typically processed the next business day and arrive within 5–8 business days. Tracking information will be provided as soon as your order ships.
Need to make a change to your order? Contact us within 24 hours of purchase, and we'll be happy to help. Please note that orders already processed for shipment cannot be canceled.
1-Year Limited Warranty: As an authorized dealer, we provide a 1-year limited warranty covering manufacturer defects in materials and workmanship under normal use. The warranty does not cover physical damage, misuse, improper installation, or normal wear and tear.
