DS18 PRO-HY6.4B PRO 6.5" Coaxial Hybrid Mid-Range Speaker | 225W RMS, 4-Ohm, Water-Resistant Cone with Built-in Driver

DS18’s PRO-HY6.4B delivers powerful sound with a hybrid design built to withstand the elements. Featuring a water-resistant paper cone, 1.5" glass fiber voice coil, and a titanium diaphragm compression driver powered by a neodymium magnet, this speaker handles 225W RMS / 450W MAX. With 96dB sensitivity and a 100Hz–20kHz range, it’s built for loud, clear audio in any environment.

Features:

• 6.5" Hybrid Coaxial Mid-Range w/Driver
• RMS Power: 225 Watts(450 Watts Peak)
• Impedance: 4 Ohm
• Ferrite & Neodymium Magnets
• Water Resistant IPX5
• Easily Repaired With The PRO-HY/VC

General Specifications:

SKU
PRO-HY6.4B
Nominal Diameter
6.5" / 165.1mm
Nominal Impedance
4 Ohm
RMS Power Handling
225W
MAX Power Handling
450W
Sensitivity (1w/1m)
96dB
Frequency Response
100Hz - 20Khz
Recommended HI Pass Crossover
120Hz
Number of ways
2 ways
Pair or Single
Single
Grill Included
Yes

UPC: 810005188340

Woofer Specifications:

Voice Coil Diameter
1.5" / 38.6mm
Voice Coil Former Material
Glass Fiber
Winding Material
CCAW
Cone Material
Water Resistant Paper (IPx5)
Surround Material
Cloth
Basket Material
Aluminum
Basket Color/Finish
Glossy Red
Magnet Material
Ferrite
Magnet Weight
27 Oz
Displacement Volume
0.047L / 0.0016ft3

Thiele & Small Parameters:

Equivalent Volume Vas
2.21L / 0.078ft3
Excursion (one way) Xmax
9.2mm
Free Air Resonance Fs
199Hz
Mechanical Factor Qms
5.96
Electrical Factor Qes
1.524
Total Factor Qts
1.214
Mechanical Mass Mms
8.654g
Mechanical Compliance Cms
73.792 mm/N
BL Factor BL
4.769
Voice Coil Inductance Le
4.22mH
Cone Area Sd
145.26 Cm2
DC Resistance Re
3.2 ohms
Mechanical Mass w/o air Mmd
6.70g

Driver Specifications:

Voice Coil Diameter
1" / 25.4mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Diaphragm Material
Titanium
Magnet Material
Neodymium
Horn Diameter
3" / 76.2mm

Speaker Measurement:

Overall Diameter
6.85" / 174mm
Overall Depth
4.28" / 108.8mm
Front Mount Baffle Cutout
5.91" / 150mm
Mounting Depth
3.92" / 99.5mm
Motor Diameter
4.65" / 118mm
