PRO 10" Water Resistant Hybrid Mid-Range Loudspeaker with Built-in Driver 350 Watts Rms 4-Ohm

Only 2 left
SKU: DS-PRO-HY10.4B
(0)
Brand New with Manufacturer Warranty
Authorized Dealer
Free Shipping
Secure Payments
Regular price $229.95 USD



  • 10" Hybrid Coaxial Mid-Range w/Driver
  • RMS Power: 350 Watts(700 Watts Peak)
  • Impedance: 4 Ohm
  • Ferrite & Neodymium Magnets
  • Water Resistant IPX5
  • 100dB ~ w/Grill
  • DS18 PRO-HY10.4B


    10” Water Resistant Hybrid Loudspeaker With 1.5” Compression Driver Horn

    The PRO-HY10.4B is a high-powered, water-resistant hybrid loudspeaker that combines a 10" midrange speaker with a high wattage driver to provide a full range of frequencies at an impressively loud volume.
    The PRO-HY10.4B features a 1.5" compression driver horn, made with a titanium diaphragm and neodymium magnet, for clear and powerful high-frequency sound.
    With a maximum power handling of 700 watts and a sensitivity of 100 dB, this speaker is perfect for those who want to place a high wattage, high volume loudspeaker with a powerful driver into their motorcycles to save on space and increase the quality of their sound.
    The water-resistant cone helps protect the speaker from the elements, making it ideal for outdoor use. The PRO-HY10.4B also has a nominal impedance of 4 ohms, a frequency response range of 40Hz-20KHz, and a recommended hi-pass crossover of 70Hz for improved audio performance and longevity, making it a great choice for a range of audio applications.
    The PRO-HY10.4B is an excellent choice for anyone seeking a powerful and versatile speaker for their sound system.

    SPECS

    SKU
    PRO-HY10.4B
    Nominal Diameter
    10" / 254mm
    Nominal Impedance
    4 Ohm
    RMS Power Handling
    350W
    MAX Power Handling
    700W
    Sensitivity (1w/1m)
    100dB
    Frequency Response
    40Hz - 20KHz
    Recommended HI Pass Crossover
    70Hz
    Number of ways
    2 ways
    Pair or Single
    Single
    Grill Included
    Yes


    Woofer Specifications

    Voice Coil Diameter
    2" / 50.8mm
    Voice Coil Former Material
    Glass Fiber
    Winding Material
    CCAW
    Cone Material
    Water Resistant Paper (IPx5)
    Surround Material
    Cloth
    Basket Material
    Aluminum
    Basket Color/Finish
    Matte Black
    Magnet Material
    Ferrite
    Magnet Weight
    49 Oz
    Displacement Volume
    2.86L / 0.1ft3


    Thiele & Small Parameters

    Equivalent Volume Vas
    21.8L / 0.76ft3
    Excursion (one way) Xmax
    10mm
    Free Air Resonance Fs
    95Hz
    Mechanical Factor Qms
    12.59
    Electrical Factor Qes
    0.995
    Total Factor Qts
    0.922
    Mechanical Mass Mms
    26.78g
    Mechanical Compliance Cms
    0.125 mm/N
    BL Factor BL
    6.851
    Voice Coil Inductance Le
    0.313mH
    Cone Area Sd
    352.99 Cm2
    DC Resistance Re
    3.4 ohms
    Mechanical Mass w/o air Mmd
    25g


    Driver Specifications

    Voice Coil Diameter
    1.5" / 38.6mm
    Voice Coil Former Material
    Kapton
    Winding Material
    CCAW
    Diaphragm Material
    Titanium
    Magnet Material
    Neodymium
    Horn Diameter
    4.25" / 108mm


    Speaker Measurement

    Overall Diameter
    10.3" / 261.5mm
    Overall Depth
    5.7" / 144.4mm
    Front Mount Baffle Cutout
    9" / 231mm
    Mounting Depth
    5.31" / 135mm
    Motor Diameter
    5.7" / 145mm
