Orion XTX1052 - 10 inch 2 Ohm Midrange Speaker | 500W RMS Power

When you need powerful, high-output midrange performance, the Orion XTX1052 10" 2-Ohm Midrange Speaker delivers impressive clarity, efficiency, and power handling. Rated at 500W RMS and 2,000W peak power, this speaker is designed to produce loud, detailed midrange frequencies while maintaining accurate vocal and instrumental reproduction. Its 2-ohm impedance provides flexible amplifier pairing options for high-output car audio systems.

Built for demanding applications, the XTX1052 features a non-pressed paper cone, treated cloth accordion surround, billet aluminum bullet phase plug, 120 oz ferrite magnet, and 3" voice coil for reliable performance at high volume levels. With 99.9 dB sensitivity and a 100 Hz–6 kHz frequency response, it delivers strong, efficient midrange output for daily systems, custom builds, and pro audio installations.

Key Features

• High-Output 10" Midrange Speaker – Delivers 500W RMS and 2,000W peak power handling for powerful midrange performance
• 2-Ohm Impedance – Provides flexible amplifier matching and wiring options for high-output audio systems
• Billet Aluminum Bullet Phase Plug – Helps improve sound clarity, dispersion, and voice coil cooling during high-power operation
• 3" Voice Coil – Designed for reliable power handling and consistent performance at elevated volume levels
• Non-Pressed Paper Cone – Provides responsive cone movement and accurate midrange reproduction
• Treated Cloth Accordion Surround – Supports controlled excursion and long-term durability
• 120 oz Ferrite Magnet – Provides strong motor force for high-output midrange performance
• Cast Basket – Adds structural strength while helping reduce unwanted resonance and vibration
• Nickel-Plated Push-Down Terminals – Provides secure and corrosion-resistant speaker connections
• High Sensitivity – 99.9 dB sensitivity allows the speaker to produce strong output efficiently
• Wide Midrange Frequency Response – Covers 100 Hz–6 kHz for detailed vocals, instruments, and musical content
• Pro Audio Design – Built for high-output car audio systems, custom builds, and demanding installations
• XTR Pro Audio Series – Engineered for powerful sound, durability, and high-performance applications

Specifications

• Model: XTX1052
• Series: XTR Pro Audio
• Speaker Size: 10"
• Speaker Type: Midrange
• Voice Coil Configuration: 2 Ohm
• Power Handling RMS: 500 Watts
• Power Handling Peak: 2,000 Watts
• Sensitivity: 99.9 dB
• Frequency Response: 100 Hz–6 kHz
• Voice Coil Diameter: 3"
• Cone Material: Non-Pressed Paper
• Surround Material: Treated Cloth Accordion
• Phase Plug Material: Billet Aluminum
• Magnet: 120 oz Ferrite
• Basket Material: Cast
• Mounting Depth: 4.21" (107 mm)
• Overall Depth: 4.72" (120 mm)
• Cutout Diameter: 9.02" (229 mm)
• Overall Diameter: 10.24" (260 mm)
• Grille Included: No
• Speaker Quantity: 1 Speaker

Package Includes

• 1 × Orion XTX1052 10" 2-Ohm Midrange Speaker
• 1 × Owner's Manual
• Mounting Hardware

SKU: ORI-XTX1052
UPC: 818550011038
