Orion XTR8US 8" Slim Underseat Subwoofer with Amplifier | 1000 Max
Orion XTR8US 8" Slim Underseat Powered Subwoofer delivers compact, punchy bass with a built-in 250W RMS amplifier, bass boost, and low-pass filter, perfect for tight spaces and easy underseat car audio installations.
Features:
- Ultra-Compact Design: Fits under seats or behind panels for serious bass without taking up space.
- Built-In 250W RMS Amplifier: Optimized for the 8” woofer, delivers up to 1000W peak power.
- Adjustable Bass Controls: Bass boost (0–12 dB), low-pass filter (50–150 Hz), and phase switch (0°/180°).
- Wired Remote Included: Adjust bass on-the-fly from the driver’s seat.
- Protected & Reliable: 4-way protection, LED status, and auto-start for safe, long-lasting performance.
Specifications:
Speaker Size: 8”
Power Handling (RMS): 250 Watts
Power Handling (Peak): 1000 Watts
Bass Boost: 0 – 12 dB
Low Pass Filter: 50 – 150 Hz
Frequency Response: 30 Hz – 150 Hz
Signal to Noise Ratio: 90 dB
Phase Switch: 0° / 180°
Dimensions (inches): 11.02” x 8.78” x 2.56”
Inputs: RCA Input / High-Level Input
Controls: Remote Control for Subwoofer Level
Power Supply: P.W.M. MOSFET
Protection: 4-Way System (thermal, overload, short, DC offset)
Illumination: Blue / Red LED Indicators
UPC: 818550010321
Free shipping is available within the 48 U.S. states. Orders placed before 11 PM ET are typically processed the next business day and arrive within 5–8 business days. Tracking information will be provided as soon as your order ships.
Need to make a change to your order? Contact us within 24 hours of purchase, and we'll be happy to help. Please note that orders already processed for shipment cannot be canceled.
1-Year Limited Warranty: As an authorized dealer, we provide a 1-year limited warranty covering manufacturer defects in materials and workmanship under normal use. The warranty does not cover physical damage, misuse, improper installation, or normal wear and tear.
Customer Support : 9:00 am to 5:00 pm
Address: 13446 Alondra Boulevard, Cerritos ,California 90703, United States
Email: info@eliteautogear.com
For technical support questions, contact us at cs@eliteautogear.com
Phone: (877)-215-8187
From Our Community
Real Installs. Real Sound.
See what enthusiasts are saying — straight from their builds
Low End You Can Feel
Bass Built for Daily Driving and Competition
Controlled Low End
Designed for tight, repeatable bass rather than one-note boom, so basslines and kick drums stay separate.
Built to Take Power
Voice coil, spider and cone materials are matched to the rated RMS so the sub handles sustained output.
Match the Enclosure
Performance depends on the box. Sealed for accuracy, ported for output. See the specs for recommended volume and tuning.
Wire It Right
Coil configuration decides your final impedance. Match it to a load your amplifier is stable at before wiring.
