Orion XTR10SWD4 10" Shallow Mount Subwoofer – Dual 4 Ohm, 400W RMS Bass Speaker

Name: Orion XTR10SWD4 10" Shallow Mount Subwoofer – Dual 4 Ohm, 400W RMS Bass Speaker
Brand: ORION
SKU: ORI-XTR10SWD4
Price: 129.95 USD
Availability: InStock

In stock

SKU: ORI-XTR10SWD4

Massive Power & Clarity

Pro-grade output

Superior Performance

Built to dominate

Advanced Technology

Precision-built

Premium Build Quality

Designed to last

$129.95 USD

Brand New with Manufacturer Warranty

Authorized Dealer

Free Shipping & Easy Returns

Secure Checkout

Massive Power & Clarity

Pro-grade output

Superior Performance

Built to dominate

Advanced Technology

Precision-built

Premium Build Quality

Designed to last

Product Details & Specs

The Orion XTR10SWD4 is a 10-inch shallow-mount subwoofer built for tight spaces while still delivering clean, controlled bass. It handles 400W RMS and 1600W peak power, making it ideal for daily bass setups in compact vehicles.

Its dual 4-ohm voice coils offer flexible wiring options for easy amplifier matching. With a 3.43" mounting depth, it fits under seats, in shallow boxes, and other space-limited installs where standard subs won’t fit.

Features:

Dual 4 ohm voice coils flexible wiring 2.5 inch copper wound for durability
UV coated paper fiber cone rigid and responsive sound
NBR rubber surround durable high excursion control
Heavy gauge stamped steel basket strong frame reduced vibration
Nickel plated push terminals secure easy wiring connections
Shallow mount design fits tight spaces without losing performance

Specifications:

Subwoofer Size: 10 (Inches)

Voice Coil Configuration: Dual 4-ohm

Power Handling (Peak): 1600 Watts

Power Handling (RMS): 400 Watts

Sensitivity: 83 dB

Frequency Response: 35 Hz - 300 Hz

Dustcap Material: Polypropylene

Cone Material: UV Coated Paper / Fiber Blend Cone

Surround Material: NBR

Magnet Information: Ceramic

Mounting Depth: 87mm / 3.43 (Inches)

Cutout Diameter: 231mm / 9.09 (Inches)

Overall Diameter: 275mm / 10.83 (Inches)

UPC: 818550019744
