Orion XTR10D4 – 10 Inch Dual 4 Ohm Car Subwoofer | 500W RMS Bass Power

Upgrade your car audio system with the Orion XTR10D4 10" Dual 4-Ohm Car Subwoofer, engineered to deliver powerful, controlled bass in a compact and versatile design. With 500W RMS and 2,000W peak power handling, the XTR10D4 is built for high-output daily systems, compact SPL builds, and multi-subwoofer configurations. Its dual 4-ohm voice coil design also provides flexible wiring options, making it easier to match the subwoofer to your amplifier and system requirements.

Built for durability and consistent performance, the XTR10D4 features a UV-coated paper and fiber blend cone paired with a Santoprene surround for controlled excursion and reliable bass reproduction. A polypropylene dustcap reinforces the cone assembly, while the ceramic magnet motor structure provides the magnetic strength needed for accurate, powerful low-frequency output. With a 5.43" mounting depth, the XTR10D4 is also well suited for space-conscious installations and can be used in either sealed or ported enclosures.

Key Features

• High-Output 10" Subwoofer – Delivers 500W RMS and 2,000W peak power handling
• Dual 4-Ohm Voice Coils – Provides flexible wiring configurations for different amplifier setups
• UV-Coated Paper/Fiber Cone – Designed for durability and controlled cone movement
• Santoprene Surround – Provides reliable excursion control and long-term durability
• Polypropylene Dustcap – Reinforces the cone assembly for improved stability
• Ceramic Magnet Motor – Provides strong magnetic force for powerful and controlled bass
• Compact Installation Depth – 5.43" mounting depth fits a variety of applications
• Sealed or Ported Enclosure Compatible – Flexible enough for different enclosure designs
• High-Output Daily Performance – Ideal for daily-driven systems, compact SPL builds, and multi-subwoofer setups

Specifications

• Model: XTR10D4
• Series: XTR
• Subwoofer Size: 10"
• Voice Coil Configuration: Dual 4-Ohm
• Power Handling RMS: 500 Watts
• Power Handling Peak: 2,000 Watts
• Sensitivity: 84.65 dB
• Frequency Response: 20–250 Hz
• Cone Material: UV-Coated Paper / Fiber Blend
• Surround Material: Santoprene
• Dustcap Material: Polypropylene
• Magnet: Ceramic
• Mounting Depth: 5.43" (138 mm)
• Cutout Diameter: 9.09" (230 mm)
• Overall Diameter: 10.35" (263 mm)

Package Includes

• 1 × Orion XTR10D4 10" Dual 4-Ohm Subwoofer
• 1 × Owner's Manual
• Mounting Hardware

SKU: ORI-XTR10D4
UPC: 818550011144
