Orion XTR10D2 – 10 Inch Dual 2 Ohm Car Subwoofer | 500W RMS Bass Power

Bring powerful, controlled bass to your car audio system with the Orion XTR10D2 10" Dual 2-Ohm Car Subwoofer. Engineered for high-output daily systems, compact SPL builds, and multi-subwoofer configurations, the XTR10D2 delivers 500W RMS and 2,000W peak power handling. Its dual 2-ohm voice coil configuration provides flexible wiring options, making it easier to match the subwoofer to a variety of amplifier configurations and system layouts.

Built for clean and consistent low-frequency performance, the XTR10D2 features a UV-coated paper and fiber blend cone paired with a durable Santoprene surround for controlled excursion. A polypropylene dustcap reinforces the cone assembly, while the ceramic magnet motor structure provides reliable control and efficiency. With a compact design and 5.43" mounting depth, the XTR10D2 is well suited for trunk installations, space-conscious builds, and both sealed and ported enclosures.

Key Features

• High-Output 10" Subwoofer – Delivers 500W RMS and 2,000W peak power handling
• Dual 2-Ohm Voice Coils – Provides flexible wiring configurations for different amplifier setups
• UV-Coated Paper/Fiber Blend Cone – Designed for durability and controlled bass reproduction
• Santoprene Surround – Provides reliable excursion control and long-term durability
• Polypropylene Dustcap – Reinforces the cone structure for added stability
• Ceramic Magnet Motor – Provides strong magnetic performance for powerful bass output
• Advanced Cooling System – Helps maintain consistent performance during extended use
• Compact Installation Design – Features a 5.43" mounting depth for space-conscious applications
• Sealed or Ported Enclosure Compatible – Flexible design works with different enclosure configurations
• XTR Series Performance – Built for high-output daily systems and performance-focused builds

Specifications

• • Model: XTR10D2
  • Series: XTR
  • Subwoofer Size: 10"
  • Voice Coil Configuration: Dual 2-Ohm
  • Power Handling RMS: 500 Watts
  • Power Handling Peak: 2,000 Watts
  • Sensitivity: 83.7 dB
  • Frequency Response: 20–250 Hz
  • Cone Material: UV-Coated Paper / Fiber Blend
  • Surround Material: Santoprene
  • Dustcap Material: Polypropylene
  • Magnet: Ceramic
  • Mounting Depth: 5.43" (138 mm)
  • Cutout Diameter: 9.09" (230 mm)
  • Overall Diameter: 10.35" (263 mm)

Package Includes

• 1 × Orion XTR10D2 10" Dual 2-Ohm Subwoofer
• 1 × Owner's Manual
• Mounting Hardware


SKU: ORI-XTR10D2
UPC: 818550011137
