Orion XTR-BP25 High-Performance Bass Processor – 10V Output & Bass Restoration
XTR-BP25 Bass Processor delivers enhanced low-frequency performance with precision sweep and width control, 10V output, ground isolation, and RCA inputs for clean, deep, and powerful bass in car audio systems.
Features:
- XTR Bass Processor: Boosts and restores low-frequency signals for subwoofers.
- Bass Restoration: Recovers lost bass from compressed or factory audio.
- Sweep & Width Control: Adjust center frequency and bandwidth for deep or punchy bass.
- Selectable Output: 2.5V, 5V, 7.5V, or 10V to match amplifier input.
- High SNR & Low Distortion: Clean bass with >110dB SNR and <0.02% THD.
- Balanced/Unbalanced Inputs: Compatible with factory and aftermarket radios.
- Ground Isolation: Reduces alternator noise and interference.
- Remote Bass Control: Adjust bass in real time from the driver’s seat.
Specifications:
Power Supply: 6.5V – 18V
Maximum Input Level: 10V
Maximum Output Level: 10.5V
Input Sensitivity: 10.5V
Input Impedance: >50K Ohms
Output Impedance: 100 Ohms
EQ Boost / Cut: 15 dB
Signal-to-Noise Ratio: >110 dB
THD @ 2V Output: <0.02%
Channel Separation: >80 dB
CMRR: -63 dB Balanced / -29 dB Unbalanced
Frequency Response: 10 Hz – 30 kHz
Subsonic Filter: 27 Hz – 72 Hz
Current Draw: 230 mA
Interchannel Gain Tracking: 0.1 dB
Fuse Rating: 1A
Dimensions: 3.98” x 6.42” x 2.09”
UPC: 818550019461
