Orion CM852 Midrange Speaker 1200 Watts Max - 300 Watts RMS
The CM852 Midrange Speaker is perfect for those seeking precision and dynamic performance in a reliable design. It delivers crystal-clear, balanced midrange frequencies and handles demanding environments with ease. Key features include a bullet phase plug for enhanced audio clarity and dispersion, a heavy-gauged stamped steel frame for strength and rigidity, and a non-pressed paper cone with a treated cloth accordion surround for durability and accurate sound reproduction. With 300 Watts RMS and 1200 Watts peak power, it offers dynamic sound performance across a wide frequency range (80 Hz to 16 kHz). Ideal for car audio enthusiasts, the CM852 combines power, durability, and precision to transform your audio experience.
Features:Â
2-Ohm Midrange Speaker:Â Delivers precise and accurate sound reproduction, integrating seamlessly into any high-performance audio system.
Bullet Phase Plug:Â Enhances sound clarity, reduces distortion, and cools the voice coil, providing consistent, high-quality audio.
Heavy-Gauged Stamped Steel Frame:Â Offers exceptional strength and rigidity, minimizing vibrations and resonance for improved sound clarity.
High-Temperature Coating:Â Protects the speaker components from heat during extended use at high power levels, ensuring consistent performance.
High Power Handling:Â 300 Watts RMS and 1200 Watts peak power for dynamic, powerful sound performance in any environment.
Durable Construction:Â Features a non-pressed paper cone and a treated cloth accordion surround for durability and accurate sound reproduction.
Wide Frequency Range:Â From 80 Hz to 16 kHz, capturing detailed midrange frequencies for a rich, immersive audio experience.
Specifications:
Speaker Size:Â 8" (Inches)
Voice Coil Configuration:Â 2 ohm
Power Handling (Peak):Â 1200 Watts
Power Handling (RMS):Â 300 Watts
Sensitivity:Â 96 dB
Frequency Response:Â 80 Hz - 16 kHz
Voice Coil Diameter:Â 1.5" (Inches)
Midrange Speaker:Â 1 Pair (2 Speakers)
Grill Included:Â No
Cone Material:Â Non-Pressed Paper Cone
Damper Material:Â Poly Cotton
Surround Material:Â Accordion Treated Cloth
Magnet Information:Â 40 Oz Ferrite
Mounting Depth:Â 81mm / 3.19 (Inches)
Overall Depth:Â 88.7mm / 3.49 (Inches)
Cutout Diameter:Â 184.5mm / 7.26 (Inches)
Overall Diameter:Â 209.4mm / 8.24 (Inches)
Â
Specification | Details |
---|---|
Model | CM852 |
Speaker Size | 8″ |
Impedance | Dual 2 Ω |
Power Handling (RMS) | 300 W |
Power Handling (Peak) | 1,200 W |
Sensitivity | 96 dB |
Frequency Response | 80 Hz – 16 kHz |
Voice Coil Diameter | 1.5″ |
Cone Material | Non‑pressed paper |
Surround | Accordion treated cloth |
Bullet Phase Plug | Yes |
Frame Material | Heavy‑gauged stamped steel |
Magnet | 40 oz ferrite |
Mounting Depth | 81 mm (3.19″) |
Overall Diameter | 209.4 mm (8.24″) |
UPC | 818550014589 |
