Orion CEA650.1D 650W RMS Class D Monoblock Amplifier – 2600W Max
Massive Power & Clarity
Superior Performance
Advanced Technology
Premium Quality
YOU MIGHT ALSO NEED
The Orion CEA650.1D Cobalt Elite Series is a compact Class D monoblock amplifier delivering up to 650W RMS of clean, controlled bass. Designed for tight, efficient low-end performance, it features a variable low-pass crossover and adjustable bass boost for easy tuning. Built-in protection circuits guard against thermal, short, and low-voltage issues, while the compact design allows simple installation in tight spaces. Perfect for upgrading factory systems or building a reliable daily bass setup.
Features:
- High-efficiency Class D design delivers strong output with reduced heat and power loss
- Built-in electronic crossover with 12dB/octave low-pass filter for precise sound tuning
- Adjustable bass boost for enhanced low-frequency control
- Compact chassis for easy installation in tight or hidden spaces
- All-MOSFET power supply and output stage for clean, stable performance
- Remote gain control included for real-time bass adjustment from the driver’s seat
- 1-ohm stable for flexible subwoofer system setups
- Heavy-duty power and speaker terminals for high current handling
- Soft turn-on/turn-off with turn-on delay for system protection
- 4-way protection: thermal, DC offset, short circuit, and voltage protection
- Intelligent LED indicator for power and fault monitoring
Specifications:
RMS WATTS @ 1 Ohms: 650W
RMS WATTS @ 2 Ohms: 500W
RMS WATTS @ 4 Ohms: 300W
POWER TERMINAL MANAGEMENT
-Positive Terminals: 1 x 4 AWG.
-Negative Terminals: 1 x 4 AWG.
-Remote Turn-ON Signal: 10 AWG.
-Speaker Output Terminals: 10 AWG.
Frequency Response: 15Hz - 250Hz
Subsonic: (15 - 40Hz)
Low Pass Crossover Continuously variable: 50 Hz - 250 Hz
Supply Voltage: 10 - 16V
Input Impedance: 22kOhm
Signal to Noise Ratio: 92dB
Phase Shift: 0/180 Degrees
Bass Boost: 0 - 12dB Variable
Variable Input Level Control: 0.2V - 6.0V
Recommended Fuse Rating: 80A
Dimensions (L x W x H): 7.87" x 5.71" x 2.13"
UPC: 818550014176
