Orion CEA1200.1D 1200W RMS Class D Monoblock Amplifier – 4800W Max

The Orion CEA1200.1D Cobalt Elite Series is a compact Class D monoblock amplifier delivering up to 1200W RMS of clean, controlled bass. Designed for powerful yet efficient low-end performance, it features a variable low-pass crossover and adjustable bass boost for easy tuning. Built-in protection circuits guard against thermal, short, and low-voltage issues, while the compact design allows simple installation in tight spaces. Perfect for upgrading factory systems or building a strong, reliable daily bass setup.

Features:

• High-efficiency Class D design delivers strong output with reduced heat and power loss
• Integrated electronic crossover with 12dB/octave low-pass filter for precise tuning
• Adjustable bass boost for enhanced low-frequency control
• Compact chassis for easy installation in tight or hidden spaces
• All-MOSFET power supply and output stage for clean, stable performance
• Remote gain control included for real-time bass adjustment
• RCA pass-through output for system expansion flexibility
• 1-ohm stable for high-performance subwoofer setups
• Heavy-duty high-current power and speaker terminals
• Soft turn-on/turn-off with turn-on delay for system protection
• 4-way protection: thermal, DC offset, short circuit, and voltage protection
• Intelligent LED indicator for power status and fault monitoring

Specifications:

MS WATTS @ 1 Ohms: 1200W

RMS WATTS @ 2 Ohms: 850W

RMS WATTS @ 4 Ohms: 500W

POWER TERMINAL MANAGEMENT

-Positive Terminals: 1 x 4 AWG.

-Negative Terminals: 1 x 4 AWG.

-Remote Turn-ON Signal: 10 AWG.

-Speaker Output Terminals: 10 AWG.

Frequency Response: 15Hz - 250Hz

Subsonic: 15 Hz - 40 Hz

Low Pass Crossover Continuously variable: 50 Hz - 250Hz

Supply Voltage: 10 - 16V

Input Impedance: 22kOhm

Signal to Noise Ratio: 92dB

Phase Shift: 0/180 Degrees

Bass Boost: 0 - 12dB Variable

Variable Input Level Control: 0.2V - 6.0V

Recommended Fuse Rating: 140A

Dimensions (L x W x H): 9.45" x 5.71" x 2.13"

UPC: 818550014190
