DS18 GEN-X 4-Channel Full-Range Amp – Class D, 150W RMS per Channel, 4-Ohm
Power your system with this full-range Class D 4-channel amplifier delivering up to 1800W. With advanced filters, high-level input compatibility, and multiple protection features, it’s built for clean sound, flexible installs, and long-lasting performance.
Features:
- 4 Channel Full Range
- Class D
- 2 ~ 4 Ohm Stable
- 4 x 150 Watts @ 4 Ohm
- Power/Protection/Clip Indicator
- Built in Crossover
Specifications:
| SKU | G1800.4D |
| UPC | 810005189958 |
| Class | Digital (D) |
| Amplifier Type | 4 CH Full Range |
| Channels | 4 CH |
| Peak Power | 1800W |
| RMS Power @ 4 Ohm | 4 × 150W |
| RMS Power @ 2 Ohm | 4 × 230W |
| RMS Power @ 4 Ohm Bridged | 2 × 430W |
| Minimum Impedance | 2Ω Stereo / 4Ω Bridged |
| Operating Voltage | 15V |
Performance & Controls:
| Frequency Response | 20Hz – 20KHz |
| Signal-to-Noise Ratio | >90dB |
| Low Pass Filter | 50Hz – 250Hz |
| High Pass Filter | 50Hz – 250Hz |
| Efficiency @ 4 Ohm | 81% |
| Damping Factor | 78 |
| THD % | 0.01% |
| Input Sensitivity | 0.25V – 6V |
| X-Over Filter Range | 50Hz – 250Hz |
Build & Protection:
| Selectable X-Over | LPF / FLAT / HPF |
| LED Indicators | Power / Protection / Clip |
| Voltage Protection | Yes |
| Clipping Protection | Yes |
| Thermal Protection | Yes |
| Cooling Fan | Yes |
| Speaker Output Size | 12GA |
| Power Input Size | 4GA |
| Fuse Rating | 80A |
| Remote Level Control | No |
| Body Color / Finish | Matte Black |
Measurements:
| Product Weight | 4 lb |
| Product Dimensions (L × W × H) | 12.25 × 6.25 × 3.25 in |
| Master Carton Weight | 25 lb |
| Master Carton Dimensions | 13 × 13 × 11 in |
| Master Carton Quantity | 6 Units |
| Sold In | Single Unit |
