DS18 NXL-LXY6 6.5” Marine Grade Luxury Coaxial Speaker, Flush Magnetic Mount Grill Digital LED & Bullet Tweeter - White | 150W RMS 4-Ohm

Out of stock
SKU: DS-NXL-LXY6/WH
(0)
Brand New with Manufacturer Warranty
Authorized Dealer
Free Shipping & Easy Returns
Secure Checkout
Regular price $449.95 USD
Massive Power & Clarity

Massive Power & Clarity

Superior Performance

Superior Performance

Advanced Technology

Advanced Technology

Premium Quality

Premium Quality

The NXL-LXY6/WH 6.5″ marine coaxial speaker delivers powerful, clear sound with all-weather durability and a clean white finish. Featuring a 6.5″ woofer and 1″ floating bullet tweeter, it provides high-output full-range audio from 40Hz–20kHz, ideal for marine and powersports applications.

Built to handle the elements, it includes an IP65-rated, UV-treated cone and rubber surround, a flush-mount magnetic grille for a seamless install, and digital LED backlighting. Compatible with DS18 LC-DRM (sold separately) for full LED color control.

Features:

  • 6.5” 2-Way Marine-Grade Coaxial Speaker
  • IP65 Water & UV Resistant Constructio
  • Floating Bullet Tweeter with Neodymium Magnet
  • Digital LED Ring (LC-DRM Compatible)
  • Flush-Mount Magnetic Grille for Clean Install

Specifications:

Nominal Diameter
6.5" / 165mm
Nominal Impedance
4 ohms
RMS Power Handling
150W
MAX Power Handling
300W
Sensitivity (1w/1m)
95 dB
Frequency Response
60Hz-20KHz
Recommended HI Pass Crossover
70Hz
Sold in Pair or Single
Pair

UPC: 810199440934


Body / Features

Grill Type
PC+Stainless Steel
Marine Grade Type
IP65
RGB LED
Yes, Digital LED integrated (behind cone)
Digital LED Chip Type
1815S
Basket Material
Injection Molded Composite ASA with UV Protection Coating
Color / Finish
Gloss White


Woofer Specifications

Voice Coil Diameter
1.5" / 38.6mm
Voice Coil Former Material
Glass Fiber
Winding Material
CCAW
Cone Material
PPI
Surround Material
Rubber
Basket Material
PC
Magnet Material
Ferrite + Neodymium
Magnet Weight
13oz + 1.1oz


Tweeter Specifications

Voice Coil Diameter
1" / 25.5mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Diaphragm Material
Aluminium
Magnet Material
Neodymium (N35H)
Magnet Weight
0.4oz


Thiele & Small Parameters

Equivalent Volume
3.15L / 0.11ft3
Excursion (one way)
3mm
Free Air Resonance
88Hz
Mechanical Factor
7.497
Electrical Factor
1.205
Total Factor
1.038
Moving Mass
16.603g
Compliance
0.1679mm/N
Bl Factor
5.138
Voice Coil Inductance
1.4mH
Diaphragm Area
114.99cm2
DC Resistance
3.2 Ohms
Efficiency Bandwidth Product
78.8

Speaker Measurement

Overall Diameter
8.35" / 212mm
Overall Depth
3.8" / 96.5mm
Front Mount Baffle Cutout
6.77" / 172mm
Mounting Depth
3.41" / 86.5mm
Motor Diameter
3.54" / 90mm
