DS18 NVY-I800.4D Full Range 4-Channel Amplifier 4 x 800 Watts RMS @ 2-Ohm

Power your system with the NVY 4-channel full-range amplifier delivering 3200W RMS (4x800W @ 2-ohm) in a compact, high-efficiency Class D design built for clean, reliable output. Engineered for durability, it features vibration-resistant bonded components, moisture-protected circuitry, and an integrated cooling fan for consistent performance under pressure. Enjoy flexible tuning with variable crossovers, easy integration with high-level inputs and auto turn-on, and full system protection including thermal, short-circuit, voltage, and clipping safeguards—perfect for high-power audio in tight installations.

Features:

• Compact Power
• Protective Coating
• Vibration Protection
• High Efficiency Micro Design
• Tiffany RCA Terminals
• Fully Variable Crossover Filters

Specifications:

Power

Total Watts (Peak): 3200W

RMS Power @ 4 Ohms: 4 x 500W

RMS Power @ 2 Ohms: 4 x 800W

RMS Power @ 4 Ohms Bridge: 2 x 1100W

Audio

Frequency Response: 10Hz – 31kHz

Signal to Noise Ratio: 102dB

Efficiency @ 4 Ohms: 88%

Damping Factor: 200

Input Impedance: 10k Ohms

Channel Separation: 52dB

Total Harmonic Distortion (THD): 1.00%

Low-Level Input Range: 0.2 – 6V

High-Level Input: Yes, with Auto Turn-On

Selectable Crossover: LPF / HPF / FULL

Crossover Filter Range: 40Hz – 2kHz

Features

Amplifier Class: Digital

Amplifier Type: Full-Range Stereo

Number of Channels: 4 Channels

Minimum Impedance: 2 Ohm (Stereo) / 4 Ohms (Bridge)

LED Indicators: Power | Protection | Clipping

Power Input Terminal Size: 4 AWG

Fuse Size: 340A (External)

Cooling Fan: Yes

Thermal Protection: Yes

Overload Protection: Yes

DC Output Protection: Yes

Short Circuit Protection: Yes

Voltage Input Protection: Yes

Clipping Protection: Yes

High-Level Speaker Connector: Yes

Tiffany RCA Terminal: Yes

LED Clip Indicator: Yes

High-Efficiency Micro Digital Design: Yes

Body Color / Finish: Black / Aluminum

UPC: 810199441290
