DS18 NVY-8HDCFSL-N2 8” Slim Hybrid Loudspeakers 250W RMS 2 Ohm – Compression Driver, Carbon Fiber Cone, Neodymium Magnet
The NVY-8HDCFSL-N2 delivers powerful, high-output sound with crisp highs and strong midrange clarity, perfect for riders and audio enthusiasts who want both loudness and precision. Its slim 2.74” mounting depth fits tight spaces like motorcycle fairings and compact enclosures, while the hybrid design with a carbon fiber woofer and compression driver ensures clean, controlled performance with reduced distortion—even at high volume.
Features:
- Carbon Fiber Cone
- Super Tweeter
- High Sensitivity
- Water-Resistant IP65
- Neodymium Magnet
- Perfect for Motorcycles and Powersports
Specifications:
Nominal Diameter: 8" (210mm)
RMS Power Handling (Combined): 250W
MAX Power Handling (Combined): 500W
Sensitivity (1W/1m) (Combined): 98dB
Frequency Response (Combined): 80Hz–20kHz
Number of Ways: 2-Way
Recommended High-Pass Crossover: 100Hz
Water-Resistant Rating: IP65
Configuration: Pair
Woofer Specifications
Nominal Impedance: 2 Ohms
RMS Power Handling: 200W
MAX Power Handling: 400W
Frequency Response: 85Hz–2kHz
Recommended Band-Pass Crossover: 140Hz–2kHz
Voice Coil Diameter: 2" (52.4mm)
Voice Coil Former Material: Glass Fiber
Winding Material: CCAW
Cone Material: Carbon Fiber
Surround Material: Cloth
Basket Material: Aluminum
Basket Color: Black
Magnet Material: Neodymium
Magnet Weight: 9.26 oz
Thiele & Small Parameters
Vas (Equivalent Volume): 6.89L (0.243ft³)
Xmax (One-Way Excursion): 1.2mm
Fs (Free Air Resonance): 110Hz
Qms (Mechanical Q): 11.700
Qes (Electrical Q): 0.393
Qts (Total Q): 0.380
Mms (Moving Mass): 19.377g
Cms (Mechanical Compliance): 0.107mm/N
BL (BL Factor): 8.140
Le (Voice Coil Inductance): 0.089mH
Sd (Diaphragm Area): 213.82cm²
Re (DC Resistance): 1.8 Ohms
Mmd (Mechanical Mass without Air): 281.93g
Driver Specifications
Nominal Impedance: 4 Ohms
AES Power Handling: 50W
Program Power Handling: 100W
Peak Power Handling: 200W
Frequency Response: 2kHz–20kHz
Recommended High-Pass Crossover: 2kHz
Voice Coil Diameter: 1.5" (37.6mm)
Voice Coil Former Material: Kapton
Winding Material: CCAW
Diaphragm Material: Aluminum Alloy
Magnet Material: Neodymium (N38H)
Magnet Weight: 1.3 oz
Horn Diameter: 2.5" (65mm)
Measurements
Overall Diameter: 8.27" (210mm)
Overall Depth: 3.11" (79mm)
Front Mount Baffle Cutout: 7" (179mm)
Mounting Depth: 2.74" (69.5mm)
Motor Diameter: 4.13" (105mm)
UPC: 810199441566
