DS18 69PRO400NMR-4 6x9” High-Sensitivity Professional Midrange Loudspeaker – 200W RMS 4-Ohm Neodymium Pro Audio Speaker for Car & SPL Systems (Single)

In stock
SKU: DS-69PRO400NMR-4
(0)
Brand New with Manufacturer Warranty
Authorized Dealer
Free Shipping & Easy Returns
Secure Checkout
Regular price $144.95 USD
Massive Power & Clarity

Massive Power & Clarity

Superior Performance

Superior Performance

Advanced Technology

Advanced Technology

Premium Quality

Premium Quality

69PRO400NMR-4 6x9” high-sensitivity professional midrange speaker delivers 200W RMS, 400W max power, and 100 dB efficiency for loud, clean, high-projection sound in car audio and SPL systems.

Features:

  • 6x9” High-Sensitivity Midrange Speaker (100 dB Output)
  • 200W RMS / 400W Peak Power Handling
  • Neodymium Magnet for Lightweight, High Efficiency
  • 100 Hz–17 kHz Frequency Range for Clear Vocals
  • Aluminum Basket with High-Performance Voice Coil

Specifications:

Nominal Diameter
6x9" / 152x228mm
Nominal Impedance
4 Ohms
RMS Power Handling
200W
MAX Power Handling
400W
Sensitivity (1w/1m)
100dB
Frequency Response
100Hz-17kHz
Recommended High-Pass Crossover
120Hz
Sold as
Single unit
Demodulating Rings
Copper Ring
Cone Shape
Curvilinear
Speaker Terminals
Push 16ga


Motor

Voice Coil Diameter
1.5" / 38.6mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Cone Material
Paper
Dust Cap Material
Paper
Surround Material
Cloth
Leads Connection Type
Spider Crossed
Basket Material
Aluminum
Basket Color/Finish
Black
Magnet Material
Neodymium
Magnet Weight
8 Oz


Thiele & Small Parameters

Equivalent Volume
11.89L / 0.419ft3
Excursion (one way)
1.65mm
Free Air Resonance
117Hz
Mechanical Factor
1.980
Electrical Factor
0.34
Total Factor
0.29
Mechanical Mass
10.49g
Mechanical Compliance
0.17mm/N
BL Factor
5.58
Voice Coil Inductance
0.37mH
Cone Area
221.67 Cm2
DC Resistance
3.6 Ohms


Measurement

Overall Diameter
6.4"x9.2" / 164x234mm
Overall Depth
3.1" / 79mm
Front Mount Baffle Cutout
5.7"x8.5" / 145x218mm
Mounting Depth
2.9" / 74.8mm
Motor Diameter
3.5" / 90mm

UPC: 810199441702
