DS18 35D200N-4 3.5" Dashboard Loudspeaker with Neodymium Magnet - 100W RMS, 4-Ohm (Pair) DS18
The DS18 35D200N-4 is a 3.5-inch loudspeaker made for dashboard locations in custom car audio systems. Its small size lets it fit where larger speakers will not, and it handles 100 watts RMS and 200 watts max with 87 dB sensitivity.
The cone combines glass fiber and composite foam, with a resin-finished dust cap, a rubber cloth surround and an aluminum basket. A neodymium magnet drives it across a 120 Hz to 20 kHz range for clear mids and highs.
With a 1.4-inch mounting depth and a 2.9-inch cutout, it drops into most factory or custom dash openings.
HIGHLIGHTS:
- 100W RMS / 200W MAX
- 87 dB sensitivity, 120 Hz - 20 kHz
- Glass fiber + composite foam cone
- Neodymium magnet and aluminum basket
- 1.4" mounting depth, 2.9" cutout
GREAT FOR:
- Factory dash speaker replacement
- Custom pro audio builds with tight spaces
SPECIFICATIONS:
| SIZE | 3.5 Inch |
| RMS POWER | 100 Watts |
| MAX POWER | 200 Watts |
| IMPEDANCE | 4 Ohm |
| SENSITIVITY | 87 dB |
| FREQUENCY RESPONSE | 120 Hz - 20 kHz |
| VOICE COIL | 1 Inch |
| CONE | Glass fiber + composite foam |
| SURROUND | Rubber cloth |
| BASKET | Aluminum |
| MAGNET | Neodymium |
| MOUNTING DEPTH | 1.4 Inch |
| CUTOUT | 2.9 Inch |
| SOLD AS | Pair |
| BRAND | DS18 |
| UPC | 810097268883 |
Free shipping is available within the 48 U.S. states. Orders placed before 11 PM ET are typically processed the next business day and arrive within 5–8 business days. Tracking information will be provided as soon as your order ships.
Need to make a change to your order? Contact us within 24 hours of purchase, and we'll be happy to help. Please note that orders already processed for shipment cannot be canceled.
1-Year Limited Warranty: As an authorized dealer, we provide a 1-year limited warranty covering manufacturer defects in materials and workmanship under normal use. The warranty does not cover physical damage, misuse, improper installation, or normal wear and tear.
Customer Support : 9:00 am to 5:00 pm
Email: info@eliteautogear.com
For technical support questions, contact us at cs@eliteautogear.com
Phone: (877)-215-8187
From Our Community
Real Installs. Real Sound.
See what enthusiasts are saying — straight from their builds
Clarity Where You Actually Hear It
Speakers Tuned for the Road, Not a Showroom
Clear Mids and Highs
Cone and dome materials are chosen to stay clean at volume, so vocals cut through road noise.
Handles Real Power
RMS is the number that matters day to day. Match it to your amplifier channel for headroom without strain.
Check the Fit
Mounting diameter and depth vary by vehicle. Compare the listed dimensions with your door, pod or panel first.
Crossover and Placement
Setting the right crossover point and aiming keeps highs smooth instead of harsh.
