Avatar Volcano 12 D1 12" Car Subwoofer – 2,500W RMS, 5,000W Max, Dual 1-Ohm, 25mm Xmax
Extreme Bass Power in a 12-Inch Package
The Avatar Volcano 12 D1 12" car subwoofer is built for serious SPL and high-output daily systems. It handles 2,500W RMS and 5,000W maximum power, and its 3-inch dual voice coil, massive ferrite motor and 25mm Xmax deliver deep, hard-hitting bass with the durability to keep up under demanding conditions.
Sold individually (1 subwoofer). Also available in a Dual 2-Ohm (D2) version for different amplifier setups.
Technical Specifications
| Spec | Details |
|---|---|
| Model | Avatar Volcano 12 D1 |
| Size | 12" |
| Voice coil configuration | Dual 1 ohm (D1) |
| Voice coil diameter | 3" |
| Voice coil wire | Copper-clad aluminum (CCA) |
| RMS power | 2,500W |
| Max power | 5,000W |
| Frequency response | 20 – 80 Hz |
| Sensitivity | 82.1 dB (D1) |
| Cone | Semi-pressed paper |
| Surround | Foam |
| Magnet | Ferrite |
| Basket | Die-cast aluminum |
| Xmax | 25 mm (0.98") |
| Mounting depth | 8.98" (228 mm) |
| Cutout diameter | 11.14" (283 mm) |
| Gross weight | 51.8 lbs (23.5 kg) |
| Sold as | Single subwoofer |
| SKU | DEF-Volcano12D1 |
| UPC | 4650185712296 |
Why Choose the Avatar Volcano 12 D1?
- 2,500W RMS / 5,000W max handling: power for high-output builds and competition-style systems
- Dual 1-ohm (D1) voice coil: flexible wiring for high-power monoblock amplifiers
- 3" high-temperature voice coil: built to handle sustained high power
- 25mm (0.98") Xmax: long, controlled excursion for deep low-end output
- Semi-pressed paper cone: stiff and light for accurate, powerful bass
- High-roll foam surround: supports the cone's excursion
- Massive ferrite motor: strong magnetic drive for high output
- Die-cast aluminum basket: strength and heat dissipation for hard use
- Frequency response 20–80 Hz: tuned for deep bass
Perfect For
- SPL and competition builds
- High-output daily systems for bass lovers
- Single or multi-sub setups with high-power monoblock amplifiers
- Sealed or ported enclosures built to the manufacturer's recommendations
Before You Buy
This is a dual 1-ohm subwoofer. Depending on how the coils are wired (in parallel or series), the final impedance will be 0.5 ohm or 2 ohms for a single sub. Make sure your amplifier is stable at the impedance you choose and delivers enough clean power. Use proper gauge wiring, a solid ground and a well-built enclosure for best results.
FAQ
How much power can the Avatar Volcano 12 D1 handle?
2,500W RMS and 5,000W maximum.
What does D1 mean?
Dual 1-ohm: the subwoofer has two 1-ohm voice coils. Wired in parallel it presents 0.5 ohm, and wired in series it presents 2 ohms.
What is the difference between D1 and D2?
The D2 version has dual 2-ohm coils, giving different final impedance options (1 ohm parallel or 4 ohms series). Choose based on your amplifier's stable load.
What size cutout do I need?
11.14" (283 mm) diameter, with a mounting depth of 8.98" (228 mm).
Is this sold as a pair?
No. It is sold individually, as a single subwoofer.
What amplifier should I use?
A high-power monoblock amplifier that is stable at your chosen final impedance and delivers close to the 2,500W RMS rating.
